Native 4K Wireless Projection System for Business and Education Presentation
WP-4500K
  • High-speed 5G Wi-Fi: No more messy cables and decrease broadcast latency, presentation through IEEE 802.11ac Wi-Fi 5
  • Native 4K Ultra HD Streaming: Delivers clear, rich video and audio experience
  • Plug-and-play: One-click projection that shares your screen to the HDMI capable display
  • 4-Split Screen and 32 Connected Devices: Project 4 devices at the same time onto one screen, with a total of up to 32 connected devices
  • Supports iOS and Android: BYOD (Bring Your Own Devices) supported improves efficiency in meetings or lectures
  • ​No Software Required: Share your display without additional software configuration

Share


More than just a Wireless Projection System
Perfect for Business and Education Presentation & Collaboration
Declutter your Space High-Speed 5G Wi-Fi
Eliminate an unsightly mess of cables, just plug the WP-4500TX transmitter into the laptop or desktop and utilizes Wi-Fi 5 802.11ac 5GHz bandwidth to wirelessly transmit audio and video with the stylish, compact design devices and tidy your space.
Native 4K Ultra HD Clear, Rich Image and Video
The small device offers Native 4K Ultra HD (4096x2160) output capability, ready for wireless output to any type of HDMI supported projector, TV, monitor, touchscreen, or display devices.

Native 4K Ultra HD
4096x2160

(Better resolution than 4K UHD)		 Full HD
1920x1080





Plug-and-Play, Just Click - Nothing Else Required
Plug-and-play with one-click to project instantly. No software is required. It is all pre-configured to share screens and join the efficient and productive meeting and interactive collaboration.
BYOD-Friendly Cross Platform Devices
The WP-4500K caters to a range of devices and connections from iOS to Android smartphone, tablet, MAC to Windows laptops and desktops, supporting 4-split screen and up to 32 connected devices. (*iOS system shared through screen mirroring and Android system shared through Google Home App.)

Versatile Connectivity - Mirror Screen

Besides the multi-screen interaction function, users can cast from multiple-to-one or one-to-multiple screen and all the way up to 32 devices connected . Such an extensible system opens new doors to large scale presentations or lectures, bringing next-gen presentation methods to reality.


Meeting or Conference Room
​Multiple-to-one Screen		 Event Space or Banquet Hall
​One-to-multiple Screens		 Classroom or Lecture Halls
​One-to-multiple Screens
Share


Model WP-4500RX (Receiver) WP-4500TX (Transmitter)
HARDWARE
Interface 1 x USB 2.0 Type A
1 x HDMI Out (HDMI1.4)
1 x DC In Power Jack
1 x RJ-45 10/100/1000Base-T PoE ports		 1 x USB 2.0 Type A
1 x HDMI Out (HDMI1.4)
Button Power Button
Reset Button		 Main Button
Side Button
LED Indicator Power Power, Wi-Fi Status, Connection
Antenna 2 x External Antennas (2T2R) 1 x Internal Antenna (1T1R)
Memory Flash 256MB NAND
Memory 1G DDR3		 Flash 256MB NAND
Memory 256MB DDR3
Power Input External Power Adapter (DC 5V, 2A, US, EU, UK, CN type)
Power over Ethernet (PoE)		 External Power USB Port (DC 5V, 1A)
Power Consumption Standby: 5W
Casting: 10W		 Standby: 2W
Casting: 5W
Mounting Type Desktop or Wall-Mount Desktop
Dimensions 120(L) x 120(W) x 27.06(H) mm 80.96(L) x 80.96(W) x 28.37(H) mm
Weight 150g 145g
WIRELESS
Standard IEEE802.11a/n/ac
Frequency 5Ghz: 5.150Ghz~5.825Ghz
Maximum Data Speed 866Mbps 433Mbps
Output Power 11a (54Mbps): 13±1.5 dBm
11n (MCS7): 12±1.5 dBm
11ac (MCS9): 10±1.5 dBm		 11a (54Mbps): 14±1.5 dBm
11n (MCS7): 13±1.5 dBm
11ac (MCS8): 13±1.5 dBm
11ac (MCS9): 11±1.5 dBm
Receive Sensitivity 11a (20MHz, 54Mbps): -71 dbm
11n(20MHz, MCS7): -71 dbm
11n(40MHz, MCS7): -69 dbm
11ac(80MHz, MCS9): -56 dbm		 11a (54Mbps): 11a (20MHz, 54Mbps): -67 dbm
11n(20MHz, MCS7): -66 dbm
11n(40MHz, MCS7): -64 dbm
11ac(80MHz, MCS9): -56 dbm
Security WPA / WPA2 (mix)
​OPEN
802.1X EAP
Operation Mode Access Point Access Point Client
OTHERS
Standard WP-4500K: Pre-configured, Plug-and-Pay
Additional WP-4500RX or WP-4500TX Installation by Web UI
Management Web UI for Advanced Setting
Video & Audio Outputs HDMI 1.4 comply with HDCP 1.4
Frame Rate Up to 30fps
Output Resolution
(WP-4500RX Receiver)		 4096x2160@24hz
3840x2160@30hz
3840x2160@25hz
3840x2160@24hz
1920x1080@60Hz
1280x720@60hz
1920x1080@50Hz
1920x1080@24Hz
1280x720@50hz
Input Resolution
(WP-4500TX Transmitter)		 4096x2160@30hz
3840x2160@30hz
1920x1080@60Hz
1920x1080i@60Hz
1280x720@60hz
1280x720@50hz
1920x1080@30Hz
1920x1080@50Hz
1920x1080i@50Hz
Max. Devices on Display 4 (4-Split screen)
Max. Number of Connected Users 32 Devices (Nodes)
Reach Up to 30m between WP-4500RX and WP-4500TX
Standard IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3af Power over Ethernet (PoE)
IEEE 802.3x Full-duplex and Flow Control
IEEE 802.3az Energy Efficient Etherent
Environmental Condition Operating Temperature: 32~104°F (0~40°C)
Storage Temperature: -32~104°F (0~40°C)
Operating Humidity: 10~90% (NonCondensing)
Storage Humidity: 5~90% (NonCondensing)
Certification CE
Package Content WP-4500K
  • Projection System (1 x WP-4500RX (Receiver) and 1 x WP-4500TX (Transmitter USB Power Cable Included))
  • 1 x Power Adpater (for WP-4500RX)
  • 2 x HDMI Cable
  • Quick Installation Guide
*Maximální výkon, přenosové rychlosti a pokrytí záleží na síťových podmínkách a faktorech životnícho prostředí.
* Specifikace a design se mohou změnit bez předchozího upozornění.
