AC1750 Long Range Dual-Band Wall Mount PoE Access Point
WAP1750
  • AC1750 Concurrent Dual-Band: Provides both simultaneous 2.4GHz (802.11n, 450Mbps speeds) and 5GHz (802.11ac, 1300Mbps speeds) wireless coverage for maximum flexibility
  • High Density: Supports high-density wireless networking for up to a hundred users simultaneously
  • Internal RADIUS Server: Built-in RADIUS server and management for up to 256 user accounts
  • Multiple SSID: Supports total 32 SSIDs, 2.4GHz x 16 and 5GHz x 16
  • Power over Ethernet: Supports IEEE 802.3at PoE and IEEE 802.3af PSE out
  • Supports alternative external power adapter
  • Security Cover: Optional specifically-designed security cover to prevent theft
  • Multiple easy mounting kits: Wall mount with bracket and magnetic template
  • Equipped with three detachable antennas

Share


The EdimaxPro WAP1750 is a highly-reliable wall-mount wireless access point designed to extend wireless network coverage for enterprise users.

With the latest wireless 802.11ac technology for improvements in the speed, reliability and quality of wireless communications, the WAP1750 provides both simultaneous 2.4GHz (802.11n, 450Mbps speeds) and 5GHz (802.11ac, 1300Mbps speeds) wireless coverage for maximum flexibility.

Three detachable antennas with 27.5dBm maximum power transmission provide larger wireless coverage for your environment.  The solid capacitors used in the WAP1750 guarantee  reliability for long term usage. Power Saving function not only saves the power consumption of the access point but also saves the power of battery for connected mobile devices.

Additionally, the WAP1750 features a gigabit LAN port with 802.3at Power over Ethernet (PD), and a gigabit 802.3af Power over Ethernet (PSE) port which can power other network devices such as access points or IP cameras when using the included 12V/4A power adapter.

The WAP1750  is ideal for wall-mounted applications such as office buildings , hotels , resorts or campuses and can also be used on a standard desktop.




AC1750 Concurrent Dual-Band
Provides both simultaneous 2.4GHz (802.11n, 450Mbps speeds) and 5GHz (802.11ac, 1300Mbps speeds) wireless coverage for maximum flexibility.



Edimax WAP-1750 AC1750 Long Range Dual-Band Wall Mount PoE Access Point WAP-1750_AC1750_Dual-Band.png









High Density
Supports a hundred users simultaneously for high-density wireless networking.



Edimax WAP-1750 AC1750 Long Range Dual-Band Wall Mount PoE Access Point WAP-1750_High_Density.png









High Power, Long Range
Features 27.5dBm antennas for both 2.4GHz and 5GHz, providing long range Wi-Fi coverage. Together with 93dBm receiver sensitivity.



Edimax WAP-1750 AC1750 Long Range Dual-Band Wall Mount PoE Access Point WAP-1750_high_power.png









Power over Ethernet
Supports IEEE 802.3at/af PD and PSE which can power other network devices.



Edimax WAP1750 AC1750 Long Range Dual-Band Wall Mount PoE Access Point WAP-1750_PoE_PD_PSE.png









Multiple SSID
Supports total 32 BSSIDs, 2.4GHz x 16 and 5GHz x 16.



Edimax WAP-1750 AC1750 Long Range Dual-Band Wall Mount PoE Access Point WAP-1750_multiple_SSIDs.png









Internal Radius Server
Built-in radius server which can manage up to 256 user accounts.



Edimax WAP-1750 AC1750 Long Range Dual-Band Wall Mount PoE Access Point WAP-1750_radius_server.png









ADVANCED FEATURES



  • Fast Boot-Up Time:
    -Client Connected to AP: <15 seconds
    -HTTP Ready: <50 seconds
    -SSID Ready: <30 seconds
    -SNMP Ready: <30 seconds
  • VLAN Tagging: VLAN tagging per SSID and Ethernet port which also works in WDS interfaces.
  • Smooth Site Survey: Minimal ping and throughput loss during site survey procedure, producing  stability for wireless connections in the local network environment.
  • WMM QoS Mapping: Configurable Wi-Fi Multimedia (WMM) parameters for better network traffic management.
  • Load Balance: Max. number of users can be adjusted for each SSID.
  • Power Saving*: Schedule access point’s wireless radio & LEDs on/off to save power usage by your access point and battery power of connected mobile devices.
  • High Speed Hand-Over Between Access Points*:  With optimized PMK-Caching, the hand-over speed of mobile clients between access points can be highly improved.
  • Advanced Qos Management & Traffic Shaping* : Traffic priority can be arrangement and managed by SSID, MAC address, port and IP address.

    *Coming soon.









APPLICATION DIAGRAM





Edimax WAP1750 AC1750 Long Range Dual-Band Wall Mount PoE Access Point WAP-1750_application_diagram.png

*Maximum performance, actual data rates, and coverage will vary depending on network conditions and environmental factors.
*Product specifications and design are subject to change without notice.
